Columbus sits on a geological patchwork of glacial till, shale bedrock, and river valley alluvium that makes site classification anything but straightforward. The Scioto River carved deep channels through limestone and dolomite, leaving behind highly variable deposits that range from stiff clay to loose sandy silts. A generic assumed site class won't capture what's actually beneath your footing. We run MASW surveys across Franklin County to measure shear wave velocity directly, delivering VS30 profiles that hold up under peer review and satisfy the IBC Chapter 16 requirements your structural engineer needs. When subsurface conditions get complex near the Olentangy River floodplain, we pair the geophysical data with test pits to ground-truth the stratigraphy and avoid surprises during excavation.

A measured VS30 of 280 m/s puts you in Site Class D under ASCE 7-22, which carries a different seismic coefficient than the default Class C your architect might assume.

Our service areas

Methodology and scope

The field setup uses a 24-channel Geometrics Geode seismograph with 4.5 Hz geophones spaced along a 46-meter spread. That length gives us sufficient depth penetration to characterize the top 30 meters without running into the bedrock refusal issues common in Columbus, where Paleozoic limestone can appear as shallow as 5 meters in the northwest corridor. We activate the source with a 10 kg sledgehammer on an aluminum strike plate, stacking 5 to 8 shots per spread to build signal-to-noise ratio above the ambient vibration from High Street traffic or nearby construction. The dispersion curve extraction follows the Park et al. (1999) phase-shift method, and inversion is constrained by known borehole data when available. For sites requiring deeper bedrock verification, we combine MASW with seismic refraction to map the top-of-rock surface across the entire parcel before foundation design begins.

MASW & VS30 Testing Columbus Ohio | Shear Wave Velocity Profiles — Technical reference — Columbus Ohio

Site-specific factors

Columbus registered a 4.4 magnitude event in 1986 near Anna, Ohio, and while the region sits outside major plate boundaries, the New Madrid Seismic Zone and the Wabash Valley Seismic Zone both generate long-period energy that affects soft soil basins. The IBC assigns a mapped spectral acceleration Ss of roughly 0.15 to 0.20g for Franklin County, but site amplification factors from ASCE 7 Table 19.3-1 can double that value if your VS30 falls below 180 m/s. We've measured profiles under 200 m/s in the Scioto floodplain deposits south of downtown, where 8 to 12 meters of compressible silty clay overlie weathered shale. Missing that amplification means your lateral system gets under-designed. A liquefaction study becomes relevant in those saturated alluvial zones, particularly where the water table sits within the upper 3 meters during spring months.

Need a geotechnical assessment?

Reply within 24h.

Email: contact@geotechnicalengineering.biz

Applicable standards

ASTM D4428/D4428M-14: Standard Test Methods for Crosshole Seismic Testing, ASCE 7-22 Minimum Design Loads and Associated Criteria for Buildings and Other Structures, IBC 2021 Chapter 16: Structural Design, Section 1613 Earthquake Loads, NEHRP Recommended Seismic Provisions for New Buildings and Other Structures (FEMA P-2082), FHWA-NHI-05-037 Geotechnical Engineering Circular No. 5: Geotechnical Site Characterization for Transportation Projects

Reference parameters

Parameter	Typical value
Measurement depth range	0 to 30+ meters (dependent on spread geometry)
Source type	Sledgehammer (10 kg) on aluminum plate, 5-8 stacks per shot
Geophone frequency	4.5 Hz vertical-component, 24-channel array
Data processing method	Phase-shift dispersion analysis, iterative inversion
VS30 classification standard	ASCE 7-22 Section 20.3, IBC 1613.2
Typical survey duration	1-3 hours per spread including field QC and re-shoots
Deliverable format	Signed PDF report with dispersion curves, VS profiles, and site class letter

Common questions

How long does a MASW survey take on a typical Columbus commercial lot?

A single spread on a 1-to-2-acre parcel takes about 2 hours of field time, including equipment setup, multiple shot stacks, and real-time quality control of the dispersion image. We can typically complete 4 to 6 spreads in a full field day, and preliminary VS30 results are shared within 24 hours via email. The signed final report follows within 48 hours.

What does MASW testing cost for a project in Columbus?

Do you need to drill borings alongside the MASW survey?

Not always, but it improves the model. MASW alone provides a reliable VS30 and site class. When we have a nearby boring log, we can constrain the inversion with known layer boundaries and reduce the non-uniqueness inherent in surface wave methods. If no borings exist yet, we can reference ODNR well logs or coordinate a single SPT drilling to calibrate the shear wave profile.

How does VS30 affect my building's seismic design category?

VS30 determines your site class, which feeds directly into the seismic design category through the site coefficients Fa and Fv in ASCE 7 Tables 19.3-1 and 19.3-2. A lower VS30 means higher amplification and potentially a more restrictive Seismic Design Category, which impacts lateral system detailing, connection requirements, and foundation tie-downs. Measuring instead of assuming often pays for itself in avoided over-design.
